Best selling model for long time generated by faithful and solid design in a basis.
The history of our honing machine started with this model.
The best seller to continue to present via many improvement and change of specification.
Suitable for "high-mix & low volume" production with easy manual operation.
|Honing Capacity (Max. Dia.)||mm||φ1.8〜φ67|
|Spindle Stroke (Max.)||mm||Max. 178 (but subject to change by bore size.)|
|Spindle Rotation Speed||min-1||250～1,500 (continuously variable transmission)|
|Spindle Motor for Rotating||kW||0.40|
|Motor for Coolant Pump||kW||0.06|
|Lighting Device||100V 60W Standing type Lamp|
|Floor Space (Width × Depth)||mm||616 x 500|
